Jiangsu Jintai Sealing Technology Co., Ltd
Jiangsu Jintai Sealing Technology Co., Ltd. was founded in 2004 , which located on Xingyuan Road, Yuanzhu Industrial Park, in Taixing, Jiangsu Province. With the accumulated years of scientific experiments and manufacture, our company has possessed sound quality management manuals and monitoring systems.
As a large comprehensive sealing technology enterprise, we specialize in researching, manufacturing and selling various types of seals, environment-friendly asbestos-free gaskets, specialized rubber material products and parts insulation materials for pneumatic and hydraulic systems. Moreover, we have formed a complete set with many industries such as shipping, power, iron and steel, chemistry, and machinery for many successive years.
Customized Requirements of Flange Metallic Gaskets
Non-standard products with special needs can be customized according to specific drawings or parameters. There are a variety of materials to choose from (304 stainless steel, 316 stainless steel, 321 stainless steel, 20cb-3Alloy alloy, HASTELLOY B2, HASTELLOY C276, INCOLOY 800, INCOLOY 600, INCOLOY X750, MONEL 400, nickel alloy 200, titanium alloy, carbon steel) . Various filling materials are also available on request (asbestos, non-asbestos, flexible graphite, PTFE, ceramics, etc.)
The Characteristics of Flange Corrugated Metallic Gasket
It can be reused in general applications and has high economic benefits. And like most Flange Metallic Gaskets, the outer ring can be made detachable, the primary seal is a metal inner layer, and the secondary seal is a metal outer layer. And the corrugated surface can produce a labyrinth seal to some extent.
The Working Principle of Flange Ring Joint Metallic Gasket
It belongs to self-sealing, and the seal is formed by contacting and pressing the gasket with the inner and outer slopes (mainly the outer slope) of the gasket groove. It is generally used for ring-shaped connection seat flanges, which can achieve strict sealing effects in high-temperature and high-pressure environments.
The Special Function of Flange Metallic Jacketed Gasket
Double-deck Flange Metallic Jacketed Gasket is also widely used to repair standard flanges that are not critical and where a soft gasket such as a compressed non-asbestos gasket can be used above a certain temperature. Since most double-wrap gaskets are custom made, there are virtually no restrictions on gasket size, shape, or configuration.
Frequently Asked Question
Do you have any question?
Small size 100 pieces will be shipped in about 2-3 days, large size 100 pieces will be shipped in about 30-40 days.
If it is a standard part that does not need a mold, it can support free proofing without free shipping. Non-standard parts need to provide mold fees or send related product references.
1. Outer diameter and inner diameter (ID&OD)
2. Thickness
3. Material
4. Provide drawings or samples
Under normal circumstances, it is packed in a composite wooden box, and prevents fillers or stable equipment to prevent product bumps during transportation.
Products can be customized according to customer needs according to drawings, and laser logo customization services are provided.
